Safe, Reliable Extinguisher: Unlike conventional cartridge extinguishers, the Ceasefire Cartridge isn’t constantly under pressure. The required pressure is created on the spot at the time of firefighting, making it one of the safest, most reliable extinguishers around.



Easy-to-use with Quick Activation: Being a spot pressure extinguisher, the Cartridge can be instantly activated by firmly pressing the trigger.



Extinguishing Agent: The Cartridge contains ABC powder as the extinguishing agent, enabling that to take on practically any kind of fire.



Safe Technology: Since these extinguishers create pressure only when required, they ensure absolute safety at all times.



Easy Refilling: Unlike conventional extinguishers, these extinguishers can be refilled immediately anywhere, thus eliminating the downtime needed to take them to and fro from the factory​.



Stainless Steel Body: The extinguisher’s stainless steel body ensures that there is no chance of corrosion.



6 year Warranty:  The 6 year Warranty means Ceasefire is looking out for the health of your fire safety products.



Application:  Fights Class A  B C and electrical fires.

Nomenclature For Portable Fire Extinguisher	Map-50 Fire-Extinguisher Cartridge Type – 4Kg	Map-50 Fire-Extinguisher Cartridge Type – 6Kg	Map-50 Fire-Extinguisher Cartridge Type – 9Kg	Map 50 Fire-Extinguisher Cartridge Type- 12Kg
Product Code	Cf-001151	Cf-001152	Cf-001153	Cf-000995
Agent	Abc Powder Map 50	Abc Powder Map 50	Abc Powder Map 50	Abc Powder Map 50
Stored Pressure / Cartridge	Cartridge Type	Cartridge Type	Cartridge Type	Cartridge Type
BIS Marking	Yes	Yes	Yes	Not Applicable
Cartridge Size	90 Gram	120 Gram	250 Gram	250 Gram
Throw	4 Meters	6 Meters	7 Meters	7 Meters
Gross Weight	8.32 To 8.48 Kg	11.08 To 11.32 Kg	16.72 To 17.08 Kg	Approx. 19.90 Kg
Net Mass	3.92 To 4.08 Kg	5.88 To 6.12 Kg	8.82 To 9.18 Kg	11.76 To 12.24 Kg
Discharge Mechanism	Squeeze Grip	Squeeze Grip	Squeeze Grip	Squeeze Grip
Applicable On Fires	A, B, C, & Electrical Started Fire	A, B, C, & Electrical Started Fire	A, B, C, & Electrical Started Fire	A, B, C, & Electrical Started Fire
IS 15683 Ratings	4A	6A	6A	Not Applicable
	144B	183B	233B	Not Applicable
Can Construction	Deep Drawn & Mig Welded	Deep Drawn & Mig Welded	Deep Drawn & Mig Welded	Deep Drawn & Mig Welded
Valve / Cap Construction	Forging And Machining	Forging And Machining	Forging And Machining	Forging And Machining
External Coating	Epoxy Polyester Powder	Epoxy Polyester Powder	Epoxy Polyester Powder	Epoxy Polyester Powder
Warranty In Years	6	6	6	6
G.A. Drawing Number	Cf/Ct-4Lb-50/Ga/01	Cf/Ct-6Lb-50/Ga/01	Cf/Ct-9Lb-50/Ga/01	Cf/Ct-12-50/Ga/01
Working Pressure	15 Bar	15 Bar	15 Bar	15 Bar
Hydrostatic Test Pressure	35 Bar	35 Bar	35 Bar	35 Bar
Dia. Of Shell (Od)	140 Mm	160 Mm	175 Mm	175 Mm
Approx. Height Of Fire Ext.	465 Mm	510 Mm	635 Mm	690 Mm
Body Thickness	1.6 Mm	1.6 Mm	2.0 Mm	2.0 Mm
Cylinder Material Spec.	Steel Cr2(Dc01)	Steel Cr2(Dc01)	Steel Cr2(Dc01)	Steel Cr2(Dc01)
Operating Temperature	-30Oc To +60Oc	-30Oc To +60Oc	-30Oc To +60Oc	-30Oc To +60Oc
Pressure Relief Valve	Burst Disk	Burst Disk	Burst Disk	Burst Disk



Technical specifications are subject to change with time due to our continuous product improvisation initiatives.
