Large-Remote-Display-Terminal---Standard(TI-002323-ST)
The RCT has additional sector based control keys
for Silence, Mute, Resound and Reset, which
allows other networked panels to selectively
respond to controls as programmed. E.g. on a site
with multiple buildings, a user may be allowed to
silence and reset fires originating in their own
building.Fires originating from other buildings are
displayed but cannot be reset.Fully on-site programmable via onboard
alphanumeric keypad or PC configuration
tools.View all information from across the network By using flash memory and an advanced graphical
display the remote terminals can be easily
configured to operate in virtually any language,
with any character set and allows for the
installer’s logo and company details to be
displayed on the LCD display during normal
operation.Fully programmable push buttons for remote
isolation, class change or general alarms.
compatible with a wide range of routing
equipment.Networked for System Display or Control Programmable switch input Graphical LCD display Intelli-Sense-NeT compatible Slide-in labels Small, robust and compact 24V DC operating voltage Disable/enable options 1-year warranty 1 Type Networkable 2 Model TI-002323-ST 3 Display White backlit 240x64 graphical LCD 4 LED Indicators 2 red (1 x Fire, 1 x Alarm), 1 green (Power) & 18 amber (Fault & System) 5 Keypads Alpha numeric keypad, navigation keys & on-board buzzer mute facility 6 Controls System keys for Mute, Reset, Silence, Resound 7 Key-Switch Input Optional level 2 access enable key switch 8 Power Supply Input 24 VDC, 115mA (/FT: 150mA) operating range 15-30V 9 External Supply Monitoring Monitored external fault input 10 Number of Fire Zones 2000 11 USB/Serial Ports 1 x USB & 1 x RS232 12 Programming Via on-board keypad or PC running Windows tools 13 Enclosure Steel IP30 14 Cable Entry 20mm knock-outs.4 x top and 4 x rear 15 Colour RAL7035 16 Metal work Options Semi flushing bezel, special finishes including Stainless & Chrome 17 Networking On-board Standard network card (TI-002325).
